Type
Copper free solid wire for Submerged Arc (SAW) welding unalloyed and low-alloyed steels up to 460 MPa yield strength
classification
AWS
A 5.17: EH12K
EN ISO
14171-A: S3Si
Applications

CEWELD® Ultra Clean S3Si is ideally suited for pipe welding, offshore structures, pressure vessels, bridge construction, crane construction, equipment construction, and steam turbine structures, where consistent mechanical properties and reproducible weld quality are essential.

Type
Copper free solid wire for Submerged Arc (SAW) welding unalloyed and low-alloyed steels up to 460 MPa yield strength
Applications

CEWELD® Ultra Clean S3Si is ideally suited for pipe welding, offshore structures, pressure vessels, bridge construction, crane construction, equipment construction, and steam turbine structures, where consistent mechanical properties and reproducible weld quality are essential.

Properties

CEWELD® Ultra Clean S3Si is a high-quality solid welding wire from the CEWELD® Ultra Clean family and offers lower friction and an improved corrosion resistant compared to copper coated wire. Due to the absence of copper Ultra Clean S3Si shows better performance when used with the multiwire and FMI process with lower impurities and a cleaner surface. CEWELD® Ultra Clean S3Si is best to be used with FL155 or FL188  basic agglomerated flux to obtain excellent impact properties down to -60°C and a yield strength exceeding 470 MPa.

Classification
AWS
A 5.17: EH12K
EN ISO
14171-A: S3Si
F-nr
6
FM
1
Suitable for

Reh ≤ 460 MPa (67 ksi) ISO 15608: 1.2, 1.3, 2.1

1.5637, 1.6217, 1.6228, 1.0044-1.09821.0035 - 1.0570, 1.0345, 1.0425, 1.0481, 1.0308 - 1.0581, 1.0307 - 1.0582, 1.0440, 1.0472, 1.0475, 1.0416 to 1.0551

10Ni14, 12Ni14, 13MnNi6-3, 15NiMn6,

S235JR-S355JR, S235JO-S355JO, S450JO, S235J2-S355J2, S275N-S460N, S275M-S460M, P235GH-P355GH, P275NL1-P460NL1, P215NL, P265NL, P355N, P285NH-P460NH, P195TR1-P265TR1, P195TR2-P265TR2, P195GH-P265GH, L245NB-L415NB, L450QB, L245MB-L450MB, GE200-GE240,

A, B, D, E, A 32-E 36

ASTM A 106 Gr. A, B, C; A 181 Gr. 60, 70; A 283 Gr. A, C; A 285 Gr. A, B, C; A 350 Gr. LF1; A 414 Gr. A, B, C, D, E, F, G; A 501 Gr. B; A 513 Gr. 1018; A 516 Gr. 55, 60, 65, 70; A 573 Gr. 58, 65, 70; A 588 Gr. A, B; A 633 Gr. C, E; A 662 Gr. B; A 711 Gr. 1013; A 841 Gr. A; API 5 L Gr. B, X42, X52, X56, X60, X65

Domex 315-460MC,MC Plus, ML

Approvals
CE, TÜV: in progress, Lloyds: in progress, DNV: in progress
Welding positions
PA
PB
PC
Redrying
Not required
Analysis
C Si Mn P S Cr Ni Mo Nb Ti V Cu
0.1 0.35 1.75 0.015 0.015 0.029
Mechanical Properties
Heat
Treatment		 RP0,2
(MPa)		 Rm
(MPa)		 A5
(%)		 Impact Energy (J) ISO-V Hardness
RT -40°C -60°C
As Welded 485 580 27 120 100 60 HRc
